100-91415
Pump Head LPP-2000.22 - High Flow
Availability on request
Max. Flow (l/min)
140
Max. diff. Pressure (bar)
4.2
Max. Viscosity
80 cP
Max. Liquid Temperature
90°C / 194°F
The standard impeller and pump casing are both fabricated from chemical resistant high purity fluorocarbon resins. Together with the rotor magnet they make up the pump head. Based on the principles of magnetic levitation, the pump’s impeller is suspended, contact free, inside a sealed casing and is driven by the magnetic field of the motor.
Specifications
| Max. Flow (l/min) | 140 |
|---|---|
| Max. diff. Pressure (bar) | 4.2 |
| Max. Viscosity | 80 cP |
| Fitting Size | 1" |
| Fitting Type | Tube |
| Pump Head Material | PFA |
| Impeller Material | PFA |
| Sealing Ring | Kalrez perfluoroelastomer |
| Wet Volume (without drain port) | ~ 320 ml |
| Wet Surface (without drain port) | ~ 72 400 mm² |
| Max. Liquid Temperature | 90°C / 194°F |
